25LC080T/SN

25LC080T/SN, SPI bus serial EEPROM, SMD, 7V, 2.1mA

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.90~1.10 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.90~1.10

PartNumber:: 25LC080T/SN

Brand:: Microchip Technology - Microchip | Pack: SMD | D/C: 02+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Constance's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-05-09

From Other Seller

Part Number:25LC080T/SN
US $0.90 - 1.10
ECA1HHG4R7

US $10.00 - 10.00 / Piece
(0) Remove
YL-G709

US $65.00 - 68.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The 25LC080T/SN is a 16K bit Serial Electrically Erasable PROM. The memory is accessed via a simple Serial Peripheral Interface (SPI) compatible serial bus. The bus signals required are a clock input (SCK) plus separate data in (SI) and data out (SO) lines. Access to the 25LC080T/SN is controlled through a chip select (CS) input, allowing any number of devices to share the same bus. There are two other inputs that provide the end user with additional flexibility. Communication to the device can be paused via the hold pin (HOLD). While the 25LC080T/SN is paused, transitions on its inputs will be ignored, with the exception of chip select, allowing the host to service higher priority interrupts. Also, write operations to the Status Register can be disabled via the write protect pin (WP).

Parametrics

25LC080T/SN absolute maximum ratings: (1)VCC: 7.0V; (2)All inputs and outputs w.r.t. VSS: -0.6V to VCC +1.0V; (3)Storage temperature: -65℃ to 150℃; (4)Ambient temperature under bias: -65℃ to 125℃; (5)Soldering temperature of leads (10 seconds): +300℃; (6)ESD protection on all pins: 4kV.

Features

25LC080T/SN features: (1)SPI modes 0,0 and 1,1; (2)3 MHz Clock Rate; (3)Single supply with programming operation down to 2.5V; (4)Low Power CMOS Technology: Max Write Current: 5 mA; Read Current: 1.0 mA; Standby Current: 1mA typical; (5)Organization: 1024 x 8 for 25LC080; (6)16 Byte Page; (7)Sequential Read; (8)Self-timed ERASE and WRITE Cycles; (9)Block Write Protection: Protect none, 1/4, 1/2, or all of Array; (10)Built-in Write Protection: Power On/Off Data Protection Circuitry; Write Latch; Write Protect Pin; (11)High Reliability, Endurance: 10M cycles (guaranteed); Data Retention: >200 years; ESD protection: >4000 V; (12)8-pin PDIP/SOIC Packages; (13)Temperature ranges supported, Commercial (C): 0℃ to +70℃; Industrial (I): -40℃to +85℃.
