Product Summary

The USBN9603-28MX is an integrated, USB Node controller. Other than the reset mechanism for the clock generation circuit, the USBN9603-28MX is identical. The USBN9603-28MX provides enhanced DMA support with many automatic data handling features. The USBN9603-28MX is compatible with USB specification versions 1.0 and 1.1, and is an advanced version of the USBN9603-28MX.

Parametrics

USBN9603-28MX absolute maximum ratings: (1)Supply Voltage: -0.5V to +7.0V; (2)DC Input Voltage: -0.5V to VCC +0.5V; (3)DC Output Voltage: -0.5V to VCC +0.5V; (4)Storage Temperature: -65°C to +150°C; (5)Lead Temperature (Soldering 10 seconds): 260°C; (6)ESD Rating: 4.5 KV.

Features

USBN9603-28MX features: (1)Low EMI, low standby current, 24 MHz oscillator; (2)Advanced DMA mechanism; (3)Fully static HALT mode with asynchronous wake-up for bus powered operation; (4)5V or 3.3V operation; (5)Improved input range 3.3V signal voltage regulator; (6)All unidirectional FIFOs are 64 bytes; (7)Power-up reset and startup delay counter simplify system design; (8)Simple programming model controlled by external controller; (9)Available in two packages USBN9603/4SLB: small footprint for new designs and portable applications; USBN9603/4-28M: standard package, pin-to-pin compatible with USBN9602-28M.

Diagrams

USBN9603-28MX pin connection

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
USBN9603-28MX
USBN9603-28MX

National Semiconductor (TI)

USB Interface IC

Data Sheet

0-1000: $2.42
1000-3000: $2.33
USBN9603-28MX/NOPB
USBN9603-28MX/NOPB

National Semiconductor (TI)

USB Interface IC

Data Sheet

0-1: $4.13
1-25: $3.32
25-100: $3.02
100-250: $2.73
